Qhov (socket) Welded Forged Gate Valve

Lub qhov (socket) -Welded Forged Gate Valve yog qhov me me - bore, siab - lub rooj vag siab siab uas muaj cov qauv hlau forged thiab lub qhov (socket) -weld kev sib txuas, tsim rau tag nrho - qhib / puv - kaw - tawm ntawm kev tswj kav kav dej.

Xa kev nug

Khoom Taw qhia

Dab tsi yog Cast Steel Check Valve

Khoom Loj

Qhov tshwm sim thiab txuas rau Class800Lb
Specification	R.P	一	1/2	3/4	1	1 1/4	1 1/2	2	2 1/2	3
Specification	F.P	1/4	3/8	1/2	3/4	1	1 1/4	1 1/2	2	2 1/2
ntsej muag	L	79	79	92	111	120	120	140	178	180
Handwheel txoj kab uas hla	W	100	100	100	125	160	160	180	200	220
Qhov siab	H	161	161	163	196	223	251	290	333	370
Flow port dimension	D	8	10.5	13.5	18	24	29	36.5	45	51
Qhov hnyav		2.22	2.3	2.39	4.24	5.7	7.05	10.9	16.8	24

Qhov tshwm sim thiab txuas rau Class900-1500Lb
Specification	R.P	一	1/2	3/4	1	1 1/4	1 1/2	2	2 1/2	3
Specification	F.P	1/4	3/8	1/2	3/4	1	1 1/4	1 1/2	2	2 1/2
ntsej muag	L	92	92	111	120	120	140	178	180
Handwheel txoj kab uas hla	W	100	100	125	160	160	180	200	220
Qhov siab	H	191	171	192	219	243	296	316	370	一
Flow port dimension	D	8	10.5	13.5	18	24	29	36.5	45	一
Qhov hnyav		2.4	2.4	4.4	6	7.2	11.4	16	23	一

Material Advantage rau Corrosive ib puag ncig

Lub cev valve yog tsim los ntawm forged steel cov ntaub ntawv{0}}xws li A105, F304, thiab F316-muab lub zog siab thiab tshwj xeeb siab tsis kam.

Nws cov qauv forged yog ntom thiab tsis muaj qhov porosity, ua rau nws zoo tagnrho rau siab -siab tshuab.

Cov khoom siv hlau tsis muaj steel muaj qhov ua tau zoo tshaj plaws rau ob qho tib si corrosion thiab kub kub, ua rau nws tsim nyog rau siv nyob rau hauv ib puag ncig hnyav tshaj tawm.

Qhov twg tuaj yeem siv Cast Steel Check Valves?

Roj & Roj

Siab -Hloov Pipeline kaw- tawm thiab Kev Tiv Thaiv Kev Nyab Xeeb

Chemical Systems

Tswj Corrosive Media

Fais fab Systems

Chav thiab Boiler Pipeline Control

Refining Facilities

Txheej Txheem Pipeline Isolation thiab Maintenance

Marine & Offshore

Pipeline Systems nrog High Sealing Requirements

Peb lub Hoobkas muaj zog rau Cast Steel Check Valve

Kev tsim khoom:Forging Equipment + Precision CNC Machining Centers + Valve los ua ke kab

Txheej Txheem Muaj Peev Xwm:Forging & Forming + Precision Machining + Sandblasting / Anti -Kev kho corrosion

Production & Delivery:Kev tsim khoom ruaj khov; Kev xa khoom sai rau cov qauv tshwj xeeb

Customization Muaj peev xwm:Kev them nyiaj yug rau Customization ntawm Kev Ntsuas Siab, Cov Khoom Siv, Kev Sib Txuas Hom, thiab Cov Txheej Txheem Ua Haujlwm

Kev Tswj Xyuas Zoo:Kev soj ntsuam cov txheej txheem (Raw Materials, Pressure Test, Sealing, Final Factory Inspection)

FAQ

Q: Cov chav kawm siab twg yog koj qhov Socket Welded Forged Gate Valves feem ntau tsim rau?

A: Cov chav kawm siab tshaj plaws ntawm Chav Kawm 150 txog 2500; Txawm li cas los xij, peb tuaj yeem muab cov kev daws teeb meem siab - raws li kev ua haujlwm tshwj xeeb.

Q: Yam tsawg kawg nkaus Order Quantity (MOQ) yog dab tsi? Koj puas txhawb nqa -batch xaj?

A: Rau cov qauv qauv, peb lees txais me me -batch xaj. Rau kev txiav txim loj dua, peb txhawb kev sib xyaw ua ke -batch kev yuav khoom uas muaj ntau yam tshwj xeeb.

Q: Lub sij hawm ua khoom xa tuaj yog dab tsi?

A: Rau cov qauv specifications, tus me nyuam yuav siv sij hawm 7 mus rau 30 hnub; lub sijhawm caij nyoog raug lees paub raws li qhov tshwj xeeb txiav txim kom muaj nuj nqis thiab kev xav tau kev cai.

Q: Cov kev xaiv khoom siv twg muaj?

A: Cov ntaub ntawv muaj xws li A105, F304, thiab F316. Peb tseem tuaj yeem muab cov ntaub ntawv tshwj xeeb alloy kom tau raws li qhov project tshwj xeeb.

Q: Koj puas muab OEM lossis kev pabcuam customized?

A: Yog, peb ua. Peb tuaj yeem kho cov chav kawm siab, qhov ntev, hom kev sib txuas, cov cim, thiab ntim khoom.

Q: Cov kev ntsuam xyuas zoo li cas ua ntej ua zaub mov xa tuaj?

A: Txhua lub valve raug kuaj lub plhaub siab, kuaj lub tog zaum, thiab kev tshuaj xyuas qhov ntev kom ntseeg tau tias ua tau raws li cov qauv tsim nyog.

Q: Koj cov khoom puas ua raws li cov qauv thoob ntiaj teb?

A: Yog lawm, peb tuaj yeem tsim cov khoom raws li cov qauv xws li API, ASME, thiab DIN kom tau raws li cov kev xav tau ntawm ntau lub khw thoob ntiaj teb.

Cim npe nrov: Tuam Tshoj socket welded forged rooj vag valve manufacturers, lwm tus neeg, Hoobkas
